LEDD500/700 C+M OEM Manufacturer LED Double Dome Operating Lamp with Camera System

Short Description:

LEDD500700C+M refers to double dome LED operating room light.
Built-in camera system and external hanging monitor can be used for training purpose. It enables monitoring and recording operations


Product Detail

Product Tags

Introduction

LEDD500700C+M refers to double dome LED operating room light.
Built-in camera system and external hanging monitor can be used for training purpose. It enables monitoring and recording operations.

Apply to

■ abdominal/ general surgery
■ gynaecology
■ heart/ vascular/ thoracic surgery
■ neurosurgery
■ orthopaedics
■ traumatology / emergency OR
■ urology / TURP
■ ent/ Ophthalmology
■ endoscopy Angiography

Feature

1. Camera System

Built-in camera, no need to hang it with another set of arms.

LED-Double -Dome-Operating-Room-Light

2. This operating room light captures and delivers images in fast speed and high quality.  Due to 10X optical zoom, the images can be viewed from every aspect.

Shdowless-Operating-Room-light

3. This operating room light can also record the operation surgery. It can be used for training and study purposes.

Monitor System

1. By broadcasting the operation, LEDD500700C+M operating room light can allow the clinic staff follow your progress without breaking the sterile field.

2. Operating room light with built-in camera and monitor provides another top view of the surgical head so that your surgical team can share surgical procedures worldwide.

Parameters:

Camera

Resolution

210 megapixel 1920(H)X 1080(V)

Communication mode

RS232

Communication protocols

HITACHI / SONY VISCA

Connector

LVCMOS-36pFPC(YCbCr 4:2:2)compatibility 110/LVDS 30P

Sensor type

1/2.9" CMOS/ 1/3"  CMOS

Scan mode

Progressive Scan

Day And Night System

Color/black and white/automatic

Minimum illumination

color:0.1Lux   black and white:0.01Lux

Synchronization mode

inter-sync

Video output

digital signal

SNR

≥50dB(AGC OFF)

Lens

IRCUT

IRCUT double filter automatic switching

Optical lenses

10X  f=5mm~50mm

field angle

H:51.8°(W)~5.86°(T)  V:39.1°(W)~4.4°(T)

Function

exposure mode

A/M

white balance

Automatic

Focus Mode

A/M

gain control

A/M

Picture Effect

Automatic/color/black and white/negative

mirroring function

Support (horizontal mirror + vertical mirror)

image rollovers

Support

Wide Dynamic

D-WDR

DNR

2D-DNR

electronic shutter

1/30s~1/10,000s

contrast ratio

Adjustable

saturation

Adjustable

Anti-fog function

Support

Marginal

Support

Generic specification

Dimensions

38.6(W)* 41(H)* 64.6(L)mm

Work Temperature/humidity

10℃~50℃,10%RH~60%RH

Storage Temp/humidity

20℃~60℃,10%RH~80%RH

power supply

DC 12V±10%

power consumption

3.5W MAX

Net weight

110g

Monitor

Main Parameter

Screen size

21.5'

Backlight Mode

LED

Display Area

475.2mm(W)×267.3mm(H)

Aspect Ratio

16: 9

Max Resolution

1920×1080

Display Color

16.7M

Pixel Pitch

0.2475(H)×0.2475(V)

Luminance

300cd/

Image Contrast

1500: 1

Viewing Angle

850/850/750/650

Response Time

8MS

Field Frequency

50Hz, 60Hz, 70Hz

Input and output

SDI IN

1

SDI OUT

1

AV IN

22(2×BNC)

AV OUT

1

S-VEDIO

1

VGA Input

1

HDMI Input

1

YPbPr/YCbCr Input

3(3×BNC)

RS232 Input(Optional)

1

Audio input

1

Audio output

1

Color system

PAL / NTSC / SECAM

OSD

Language

Chinese/English/French/German/Italian/Spanish/
Portuguese/Dutch/Polish

Power supply

Power

DC 12V, 50/60Hz

Pmax

35W-55W

Standby Power

5W
